Help with fixtures

Test fixture requirement selection:

Low Voltage
  • Low cost Kelvin - TF10/TF15 - for use with RT290, Reflex 10, Reflex 20 or 3rd party
  • Manual control - TF10-POT - for use with RT290, Reflex 10, Reflex 20 or 3rd party
  • Pneumatic Kelvin ZIF - TF100 - for use with RT290, Reflex 10, Reflex 20 or 3rd party
  • Manually operated Kelvin ZIF - ASY3000 - for use with RT290, Reflex 10, Reflex 20 or 3rd party
  • Multiplexing Kelvin fixture - TF200 - for use with RT290, Reflex 10, Reflex 20 or 3rd party
  • High current - ASY0700 - Kelvin 10 Amp contact load add on for RT290, Reflex 10, Reflex 20
  • Wetting current - TF20 - applies 24V/1A contact wetting load. Other loads available
Multiplexers
  • Two test site mux - ASY0697 - for use with RT290 or Reflex 10
  • Coil / contact mux - ASY725 - for use with RT290 or Reflex 10
AC/DC coil PSU
  • AC/DC coil PSU - ASY0710 - for use with RT290
  • AC/DC coil PSU - ASY0910 - for use with Reflex 510
Other products
  • USB interface - ASY5672 - for use with Reflex test systems running Artworks 5 (excluding the Reflex 51)
  • TF100

    Pneumatically operated ZIF Kelvin test fixture for through hole mounted components. Interchangeable inserts provide custom solution to a variety of device footprints.

  • TF200 - Discontinued

    Multiple site test adaptor offering increased operator efficiency through bulk loading and unloading of DUTs. For use with 3rd party test fixtures or customer/ART supplied Kelvin device sockets.

  • ASY3000

    ZIF and surface mount test fixture mounted in heavy duty enclosure. All connections are fully Kelvin.

  • ASY0700

    30V/10A contact load unit provides high current contact load environment for use with ART parametric test systems.

  • TF10/TF15

    Low cost test fixtures provides Kelvin connection to the DUT. Available in kit or ready built versions. The TF10 and TF15 handle footprint sizes up to 2" x 2" and 3" x 3" respectively.

  • TF10-POT

    Adds a manual voltage or current adjustment to the coil power supply during a test sequence to permit manual adjustment of relay characteristics during assembly or re-work.

  • TF20

    Relay contact wetting fixture. Automatically cycles relay contact whilst applying high level contact load. Compatible with TF10/TF15 fixtures.

  • TF40

    Multiple device test Kelvin fixture for use with ARTs range of life test systems such as the Reflex 40 (stick and miss test system) and Reflex 51 (relay life test system).

  • ASY0697

    Allows automatic or manual multiplexing between a relay test system and up to two test fixtures.

  • ASY0725

    Allows either parametric system coil and contacts connections to be multiplexed onto any device pin.

  • ASY0710 - Discontinued

    Adds high power coil drive to the RT290 for both AC and DC coils. Includes auxiliary output option for timing relay control.

  • ASY0910

    Adds high power coil drive to the Reflex 510 for both AC and DC coils. Includes auxiliary output option for 10A/ 5A 24Vrms contact power.

  • ASY5672

    Provides a USB interface from host PC to Reflex test systems running Artworks 5 (excludes the Reflex 51).
